Seta-Shell Four Ball Tester-Autoload - 19900-3

Methods
ASTM D2266
ASTM D2596
ASTM D2783
ASTM D4172
IP 239
BS EN ISO 20623
BS ISO 26422
DIN 51 350

The Autoload Seta-Shell Four Ball Lubricant Tester determines the friction properties of extreme pressure oils and greases. Used in tribology research laboratories and in the routine quality control of finished lubrication products.

A ball, mounted in a chuck, is rotated against three stationary balls in a pot containing the sample lubricant. The digital speed controller has three factory pre-programmed settings which are 1200, 1475 and 1760 rpm. A load, adjustable in the range of 6 to 800 kgF, is applied to the balls via a balance beam and electric jack. The applied load is displayed on a digital readout. The torque transferred between the rotating and stationary balls is measured and displayed. The digital timer, with a range of 0.1 seconds to 9999 hours, can be used to control the duration of the test. If the torque exceeds a preset level, or the balls weld, during a test, power to the drive motor is automatically turned off.

Seta-Shell Four Ball Tester-Autoload - 19900-3

Features

  • Drive speed from 1200 to 1760rpm
  • Torque measurement and limiting
  • Full Digital Control
  • Digital displays of applied load, torque, time
  • Safety splash guard

Additional Information

The optional Seta Wear Loading Kit (19940-0) allows the user to quickly convert the equipment into a Four Ball Wear Tester for ASTM D2266 and D4172 tests.

Supplied with;
1000 IP 239 test balls (ISO 683-17, ISO 3290-1 Grade G5)
Torque wrench with adjusting key and certificate of calibration
Instruction manual

Speed Range1200 to 1760 rpm
Load Range6 to 800 kgF
Timing0.1s to 9999 hr
Voltage220/240 V 50/60 Hz
Power2.6 kW
Size (HxWxD)165 x 82 x 62 cm
Weight180 kg
CCCN CodeTariff 90319000

Methods

ASTM D2266
ASTM D2596
ASTM D2783
ASTM D4172
IP 239
BS EN ISO 20623
BS ISO 26422
DIN 51 350
ASTM D2596 Standard test method for measurement of extreme-pressure properties of lubricating grease
ASTM D2783 Extreme pressure properties of lubricating fluids (Four-ball Method)
ASTM D2266 Wear preventive characteristics of lubricating grease (Four-ball method)
ASTM D4172 Wear preventive characteristics of lubricating fluid (Four-ball method)
IP 239 Determination of extreme pressure and antiwear properties of lubricating fluid - Four ball method (European conditions)
BS EN ISO 20623 Petroleum and related products. Determination of the extreme-pressure and anti-wear properties of fluids. Four ball method
BS ISO 26422 Shear stability of lubricating oils containing polymers using a tapered roller bearing
DIN 51 350 Determination of welding and metal loads using 4-Ball Tester
