Silver and Copper Corrosion Bath - 11400-7

Methods
ASTM D130
ASTM D4048
ASTM D4814
ASTM D7667
ASTM D7671
IP 154
IP 611
BS 2000-112 & IP 112
BS EN ISO 2160 & BS 2000-154 & ISO 2160

The bath is a stainless steel water or oil bath, digitally controlled to ±0.1 °C over a temperature range of ambient +5 °C to 150 °C, used to determine the corrosive effects of fuels, lubricants and other hydrocarbon products on copper and silver.

The bath has nine test stations, each with a lid and hook for suspending either a Corrosion Pressure Vessel (11500-0) or a test tube Support Assembly (11420-0). The test tube support can hold up to three Test Tubes (11590-0). You can use any combination of copper corrosion vessels and test tube supports.

Silver and Copper Corrosion Bath - 11400-7

Features

  • Maximum capacity of 27 tubes
  • programmable digital temperature controller
  • Thermometer port
  • Digital timer
  • Digital setting and control of temperature
  • Accommodates both copper and silver tests
  • Water or oil filled
  • Overtemperature cut-out and level switch

Additional Information

The top mounted thermostir unit incorporates over-temperature and low-level protection devices.

A Silver Corrosion Kit (11510-0) is available to convert six of the test stations to hold the Glassware silver Corrosion (11430-0) required for silver corrosion tests.

Supplied with;
9 x lids
Mains lead
Instruction manual

Temperature rangeAmbient +5 °C to 150 °C
Temperature stability±0.1 °C
Bath fluidWater or Oils
Bath capacity34 Litres
Heater power1500 W
Water Inlet Nozzle10 mm
Overflow drain10 mm
Voltage110/120 V, 60 Hz or 220/240 V, 50 Hz
Size (HxWxD)52 x 45 x 33 cm
Weight10 kg
CCCN CodeTariff 84198998

Methods

ASTM D130
ASTM D4048
ASTM D4814
ASTM D7667
ASTM D7671
IP 154
IP 611
BS 2000-112 & IP 112
BS EN ISO 2160 & BS 2000-154 & ISO 2160
ASTM D4814 General Specification for Automotive Spark Ignition Engine Fuels
BS EN ISO 2160 & BS 2000-154 & ISO 2160 Copper Corrosion from Petroleum Products by the Copper Strip Tarnish Test
ASTM D4048 Standard test method for detection of copper corrosion from lubricating grease
BS 2000-112 & IP 112 Determination of corrosiveness to copper of lubricating grease. Copper strip method
IP 154 Corrosiveness to Copper - Copper Strip Test
ASTM D130 Standard Test for Corrosiveness to Copper from Petroleum Products by Copper Strip Test
ASTM D7671 Corrosiveness to Silver by Automotive Spark–Ignition Engine Fuel–Silver Strip Method
IP 611 Corrosiveness to silver of automotive gasoline - Silver strip method
ASTM D7667 Corrosiveness to Silver by Automotive Spark-Ignition Engine Fuel—Thin Silver Strip Method
