Setamatic Penetrometer - 17500-0

Methods
ASTM D5
ASTM D217
ASTM D937
ASTM D1321
ASTM D1403
ASTM D1831
ASTM D7342
IP 49
IP 50
IP 179
IP 310
IP 376
BS 1377
BS 2000-50
BS 2000-179
BS EN 1426 & BS 2000-49
BS EN 13880-2
DIN 51 579
DIN 51 580
ISO 2137

The Setamatic Penetrometer is a microprocessor-controlled instrument with a range of 0 to 63 mm (630 Pen). Plunger release and retention is automatic and results are shown on the digital display in either millimetres or ‘pen’ units. Soak and penetration times may be set from 0 to 9999 seconds. An RS232C interface is provided for connection to a personal computer.

Setamatic Penetrometer - 17500-0

Features

  • Microprocessor controlled
  • Penetration range 0 to 630 Pen (63 mm)
  • Timer range 1 to 9999 seconds
  • Automatic plunger release and retention
  • Flexi light
  • RS232C interface

Additional Information

The machined aluminium base is fitted with a flexible light with dimmer switch, and a spirit level. The counterbalanced head has a geared two-speed raising and lowering mechanism, and contains the control circuits, keypad and fluorescent display. The head may be rotated through 180°.

Supplied with;
47.5 g plunger
50 g and 100 g plunger weights
Mains lead
Instruction manual

Penetration Range0 to 630 Pen (63 mm)
Penetration Time1 to 9999 seconds, fully variable
Retention/ReleaseAutomatic
Display4 Digit, Fluorescent
Voltage110/120 V or 220/240 V, 50/60 Hz (switchable)
Power40 W
Size (HxWxD)59 x 30 x 33 cm
Weight12.5 kg
CCCN CodeTariff 90248090

Methods

ASTM D5
ASTM D217
ASTM D937
ASTM D1321
ASTM D1403
ASTM D1831
ASTM D7342
IP 49
IP 50
IP 179
IP 310
IP 376
BS 1377
BS 2000-50
BS 2000-179
BS EN 1426 & BS 2000-49
BS EN 13880-2
DIN 51 579
DIN 51 580
ISO 2137
ASTM D1831 Standard test method for roll stability of lubricating grease
ASTM D5 Standard Test Method for Penetration of Bituminous Materials
ASTM D217 Cone Penetration of Petrolatum
ASTM D937 Standard Test Method for Cone Penetration of Petrolatum
ASTM D1321 Standard test method for needle penetration of petroleum waxes
ASTM D1403 Standard test methods for cone penetration of lubricating grease using one-quarter and one-half scale cone equipment
IP 49 Penetration of Bituminous Minerals
IP 50 Determination of cone penetration of lubricating grease
IP 179 Determination of cone penetration of petroleum
IP 310 Determination of cone penetration of grease - One-quarter and one-half scale cone method
IP 376 Determination of needle penetration of petroleum wax
BS 1377 Methods of test oils for civil engineering purposes
DIN 51 579 Needle Penetration of Petroleum Waxes
DIN 51 580 Cone Penetration of Petroleum
ISO 2137 Cone Penetration of Petrolatum
BS 2000-179 Determination of cone penetration of petrolatum
ASTM D7342 Shear Stability of Lubricating Grease in Presence of Water (Water Stability Test)
BS EN 1426 & BS 2000-49 Bitumen and bituminous binders. Determination of needle penetration
BS 2000-50 Determination of cone penetration of lubricating grease
BS EN 13880-2 Hot applied joint sealants. Test method for the determination of cone penetration at 25°C
