Seta Univeral Stirrer - 24600-0

Methods
ASTM D36
IP 58
BS EN 1427 & BS 2000-58
ISO 5940-2

A variable speed stirrer with a range of 100 to 2000 rpm. The stirrer is designed for use with fluids having viscosities up to 10,000 mPas, and develops a maximum torque of 15 Ncm. An overload protection device limits the power to the motor in the event of excessive load on the stirrer.

The stirrer is equipped with a keyless chuck which can accommodate up to 13 mm diameter shafts, and can be mounted on a standard 12.7 mm retort stand.

Seta Univeral Stirrer - 24600-0

Features

  • Variable speed - 100 to 2000 rev/min
  • Overload protection
  • Keyless chuck

Additional Information

Supplied with;
Retort clamp
Instructions

Speed Range100 to 2000 rev/min
Maximum Torque15 Ncm
Power50 W
Voltage220/240 V, 50/60 Hz
Size (H x W x D)23 x 8 x 24 cm
Weight2 kg
CCCN CodeTariff 90330000

Methods

ASTM D36
IP 58
BS EN 1427 & BS 2000-58
ISO 5940-2
ASTM D36 Standard Test Method for Softening Point of Bitumen (Ring-and-Ball Apparatus).
IP 58 Softening Point of Bituminous Materials - Ring and Ball Method
ISO 5940-2 Softening Point of Bituminous Materials - Ring and Ball Method
BS EN 1427 & BS 2000-58 Bitumen and bituminous binders. Determination of the softening point. Ring and Ball method
